Professional Consumer Drone & UAV Flight Controller PCBA
SZH has its own fully self-contained production plant with several high-precision SMT lines at the core, and additionally DIP, testing, and assembly lines. Thus, they can provide flexible manufacturing from prototype up to mass PCB assembly.
High-Precision SMT Lines: Able to mount 01005 components, 0.3mm pitch BGA, QFN, and other fine-pitch packages.
Complete Process Coverage: SMT double-sided, mixed assembly, selective soldering, and press-fit technology are all included.
Strict Quality Control: Inspection throughout the whole process with SPI, AOI, X-Ray, functional testing, and aging test systems.
- SZH
- China
- Information
Core Strengths
Industrial-Grade Reliability and Stability
Featuring an 8-layer gold-plated PCB process that ensures perfect signal integrity and very strong electromagnetic interference (EMI) immunity.
Flexible voltage input range, support different battery configurations, and carries a built-in power protection circuit.
Operating temperature range: -20°C to 85°C, suitable for complex environments (high altitude, low temperature, high humidity).
Intelligent Algorithms & Software Ecosystem
Automstic flight performance optimization with built-in adaptive PID tuning algorithms.
Compatible with open-source firmware and customizable SDK for easy secondary development and feature extension.
Lightweight and Highly Integrated Design
Compact dimensions (e.g., 65mm × 45mm) and ultra-lightweight (approximately 20g) design maximize space utilization and payload efficiency.
The system integrates an inertial measurement unit (IMU) with a gyroscope and accelerometer, a barometer, and a compass to reduce external wiring and enhance system reliability.
Technical Specifications
| Parameter | Details |
|---|---|
| Main Controller | 32-bit ARM Cortex-M7 architecture with a clock frequency ≥400MHz and integrated FPU |
| Sensors | 6-axis inertial measurement unit (IMU) (acceleration ±16g, gyroscope ±2000°/s High-precision Barometer 3-axis Magnetometer (Optional) |
| Communication interfaces | 3 UARTs, 1 CAN, 2 I2C,2 SPI, and 1 USB 2.0 |
| Input Power | DC 3.3V-5.5V, Peak Current ≤2A |
| Operating Environment | -20°C to 85°C, humidity: 10%~90% (non-condensing) |
| Dimensions | 65mm × 45mm × 10mm (Customizable) |
Application Scenarios
Drone Aerial Photography & Entertainment: Enables precision tracking, automatic return, and gesture recognition.
Agricultural Spraying & Surveying: Supports automated operations with accurate route planning and terrain modeling.
Security & Detection: Compatible with visual/thermal imaging modules, ideal for power line inspection, on-site monitoring, and search-and-rescue operations.
Education & R&D: Utilizes open-source hardware architecture, perfect for algorithm development, scientific research, and academic projects.
Why Choose Our Flight Controller PCBA?
Ready-to-Use Solution: Delivers complete hardware reference designs and underlying drivers to accelerate time-to-market.
Continuous Firmware Updates: Our team regularly refines flight algorithms with free functionality and safety upgrades.
Professional Support: Circuit diagrams, layout guides, and debugging tutorials enable rapid integration and troubleshooting.
Rigorous Quality Control: Full-process ATE testing and high/low-temperature aging tests ensure defect rates below 0.1%.
Support & Services
Supports customized services (including interface modification, size adjustment, and chipset replacement).
Provides development kits (including debugger, carrier board, and basic code library).
Bulk orders can be offered with joint debugging and firmware customization services.
Accurate and reliable, making flights more powerful—Drones 'professional' flight brain'..
