Quick Turn Prototype PCBA Service with Free DFM Check
SZH operate a fully self-owned production base equipped with multiple high-precision SMT lines, complemented by DIP, testing, and assembly lines. This enables flexible production from prototyping to large-scale PCB assembly.
High-Precision SMT Lines: Support 01005 components, 0.3mm pitch BGA, QFN, and other fine-pitch package assembly.
Full-Process Coverage: Including double-sided SMT, mixed assembly, selective soldering, and press-fit technology.
Rigorous Quality Control: Full-process inspection with SPI, AOI, X-Ray, functional testing, and aging test systems.
- SZH
- China
- Information
Service Overview: Accelerate Your Journey from Concept to Production
We specialize in providing rapid prototype delivery in as fast as 24 hours, coupled with a complimentary professional DFM (Design for Manufacturability) check. This ensures your design is optimized for manufacturing feasibility before committing to mass production, significantly reducing development risks and costs.
Core Advantages: Why Choose Our Service?
Lightning-Fast Turnaround, Seize Market Opportunities
Standard 24-72 Hour Delivery: PCBA prototypes completed within 24 hours of file receipt
Seamless Transition: Smooth progression from design verification to low-volume pilot runs
Free Professional DFM Analysis
Identify Issues Early: Detect potential manufacturing flaws in your design before production
Actionable Optimization Suggestions: Receive specific modification advice to enhance board reliability
Cost Savings: Avoid costly re-spins due to design defects, saving up to 30% in development costs
One-Stop PCBA Solution
Full-range service from PCB fabrication, component sourcing, SMT assembly, DIP insertion, to testing
Support for various processes: double-sided SMT, mixed assembly, BGA, fine-pitch components, etc.
ISO9001 compliant quality management system
Service Details: How We Serve You
1. Rapid Prototyping Workflow
File Upload → Free DFM Analysis → Instant Quote → Order Confirmation → Fast-Track Manufacturing → Strict QC → On-Time Delivery
2. Complimentary DFM Check Includes
PCB Design Review: Min. trace width/spacing, aspect ratio, solder mask bridges, etc.
Component Layout Analysis: Part spacing, placement conflicts, thermal considerations
Assemblability Assessment: Placement accuracy requirements, special process feasibility
Testability Recommendations: Test point design, fixture compatibility
3. Technical Specifications
| Parameter | Capability Range |
|---|---|
| PCB Layers | 1-20 Layers |
| Min. Trace Width/Space | 3/3 mil |
| Component Types | 01005, BGA, QFN, Fine-Pitch ICs, etc. |
| Placement Accuracy | ±0.025mm |
| Soldering Process | Lead-Free Soldering, Selective Soldering |
| Testing Services | AOI, X-Ray, Flying Probe Test, Functional Test |
Ideal Applications
R&D Verification: Functional testing and performance validation for new products
Design Iteration: Rapidly validate the effects of design modifications
Low-Volume Pilot Runs: Pre-market testing and small batch production
Startup Products: Initial sample builds for hardware startup teams
Emergency Replacement: Urgent repair or replacement needs for existing products
Quality Assurance System
Three-Tier Quality Protection
Incoming Material Inspection: All components sourced from certified suppliers and rigorously inspected
Process Control: SPC (Statistical Process Control) monitoring throughout production
Final Testing: Customized testing protocols to ensure every board meets specifications
Customer Support & Service
? Dedicated Engineering Support
One-on-one communication with your assigned customer engineer
Technical support team providing design consultation
Flexible handling of design changes and special requests
Global Logistics Network
Worldwide shipping
Multiple logistics options
Real-time package tracking
Frequently Asked Questions
Q1: How long from file submission to receiving samples?
A: Standard lead time is 24-72 hours, depending on design complexity and component availability.
Q2: Is the DFM check truly free?
A: Yes, we provide a free DFM analysis report regardless of whether you proceed with our service.
Q3: What is the minimum order quantity (MOQ)?
A: No MOQ for prototyping services. We accept orders starting from 1 piece.
Q4: Which design file formats are supported?
A: We accept Gerber RS-274X, ODB++, native PCB files (Altium, PADS, Cadence, etc.), BOM, and centroid/pick-and-place files.
Q5: Do you offer component sourcing?
A: Yes, we provide full-component procurement and supply chain management services.
Start Your Project Now
Get Your PCBA Prototype in 3 Simple Steps:
Upload Your Design Files (Gerber, BOM, Pick-and-Place)
Receive Free DFM Report & Quote (Response within 2 hours)
Confirm Order & Start Production
Let Our Expert Team Accelerate Your Hardware Innovation — From Concept to Working Prototype, We Partner with You Every Step of the Way!
