Rigid-Flex & Flexible PCB (FPC) Assembly Services
SZH operate a fully self-owned production base equipped with multiple high-precision SMT lines, complemented by DIP, testing, and assembly lines. This enables flexible production from prototyping to large-scale PCB assembly.
High-Precision SMT Lines: Support 01005 components, 0.3mm pitch BGA, QFN, and other fine-pitch package assembly.
Full-Process Coverage: Including double-sided SMT, mixed assembly, selective soldering, and press-fit technology.
Rigorous Quality Control: Full-process inspection with SPI, AOI, X-Ray, functional testing, and aging test systems.
- SZH
- China
- Information
Full-Service PCBA Capabilities
1. Design Support Services
DFM Analysis: Early risk identification and design optimization
3D Modeling: Assembly feasibility verification
Signal Integrity Analysis: Ensures high-frequency/high-speed signal quality
2. Precision Assembly Processes
Fine-Pitch Placement: 01005 components, 0.3mm pitch BGA
FPC-Specific Tooling: Custom carriers to prevent deformation
Selective Coating: Localized conformal coating while maintaining flexibility
3. Quality Control System
Quality Assurance Process:
1. Incoming Inspection → 2. First Article Confirmation → 3. In-Process Inspection
4. X-ray Inspection → 5. Functional Testing → 6. Reliability Verification
Industry Applications
1. Consumer Electronics
Foldable smartphone hinge area circuits
TWS earphone charging case internal connections
Smartwatch/wearable device motherboards
2. Medical Devices
Wearable medical monitoring equipment
Minimally invasive surgical instruments
Portable diagnostic devices
3. Industrial & Automotive
Industrial robot joint wiring
Automotive sensor harnesses
Vehicle display modules
4. Aerospace & Defense
Satellite solar panel deployment mechanisms
UAV folding wing connections
Weight reduction solutions for avionics
Advantages vs. Traditional PCBs
| Comparison Dimension | Traditional Rigid PCB | Rigid-Flex/Flexible PCB |
|---|---|---|
| Space Utilization | 2D planar layout | 3D routing, saves 40%+ space |
| Weight | Heavier | Up to 60% weight reduction |
| Reliability | Connector failure points | Integrated structure, fewer failure points |
| Vibration Resistance | Moderate | Excellent for dynamic environments |
| Assembly Cost | Multi-component assembly | Simplified assembly process |
5. Project Collaboration Process
5-Step Project Initiation:
1. Requirements Consultation → 2. Solution Evaluation → 3. Quotation Confirmation
4. Prototype Manufacturing → 5. Mass Production
Rapid Prototyping: 7-10 working days for functional samples
Mass Production Lead Time: 2-4 weeks (depending on complexity)
Certifications & Testing Capabilities
Certification System
ISO 9001:2015 Quality Management System
IATF 16949 Automotive Standard
IPC-A-600/610 Class 2/3 Standards
Reliability Testing
Flex Testing: 100,000+ dynamic bend cycles
Environmental Testing: -40°C~125°C thermal cycling
Mechanical Testing: Vibration, shock, drop tests
Chemical Testing: Corrosion resistance, humidity testing
Why Choose Our Services?
Technical Expertise
10+ years specialized experience in rigid-flex technology
PhD-led process R&D team
100K+ monthly FPC production capacity
One-Stop Solution
End-to-end support from design to assembly
Component procurement & supply chain management
After-sales technical support & rapid response
Cost Optimization
Design-phase cost control recommendations
Material selection optimization
Economies of scale for volume production
8. Request Your Custom Solution
Free Design Review: Submit your design files for manufacturability analysis within 24 hours
Sample Request: Low-volume trial production available for design validation
Technical Consultation: Our engineering team is ready to answer your technical questions
