High-Quality Consumer Electronics PCBA Assembly
SZH operate a fully self-owned production base equipped with multiple high-precision SMT lines, complemented by DIP, testing, and assembly lines. This enables flexible production from prototyping to large-scale PCB assembly.
High-Precision SMT Lines: Support 01005 components, 0.3mm pitch BGA, QFN, and other fine-pitch package assembly.
Full-Process Coverage: Including double-sided SMT, mixed assembly, selective soldering, and press-fit technology.
Rigorous Quality Control: Full-process inspection with SPI, AOI, X-Ray, functional testing, and aging test systems.
- SZH
- China
- Information
Product Overview
A professional-grade PCBA (Printed Circuit Board Assembly) solution for consumer electronics, providing high-reliability, high-efficiency circuit board assembly services for smart devices, home appliances, wearable technology, and more. Utilizing advanced processes and stringent quality control to ensure every motherboard meets the demands of high-performance consumer electronics.
Core Advantages
?️ Superior Quality Assurance
Industrial Standards: Compliant with IPC-A-610 Class 2/3 standards, suitable for consumer electronics and high-reliability products
Full-Process Inspection: Includes AOI (Automated Optical Inspection), X-Ray inspection, Functional Circuit Testing (FCT), and aging tests
High-Precision Placement: Supports 01005 micro-component placement, BGA pitch down to 0.3mm
⚡ Fast & Flexible Production Capability
Rapid Prototyping: Sample delivery within 5-7 working days
Volume Production: Monthly capacity up to 5 million points, supports flexible order requirements
High-Mix, Low-Volume Adaptability: Ideal for diverse, small-batch consumer electronics projects
? Advanced Process Technology
Double-Sided SMT Assembly: Increases board integration and performance
Selective Wave Soldering: Ensures reliability for through-hole components
Conformal Coating Process: Provides moisture, corrosion, and dust protection
Flexible Circuit Assembly: Supports FPC and rigid-flex PCB assembly
Technical Specifications
Manufacturing Capabilities
| Parameter | Specification |
|---|---|
| PCB Layers | 1-20 layers |
| Minimum Component Size | 01005 (0.4×0.2mm) |
| Minimum BGA Pitch | 0.3mm |
| Min. Trace Width/Spacing | 3/3 mil |
| Placement Accuracy | ±0.025mm |
Material Options
PCB Substrate: FR-4, High-Frequency Materials, Aluminum Base, Ceramic Base
Soldering Process: Lead-free, RoHS compliant
Surface Finish: ENIG, OSP, Immersion Silver, Immersion Tin
Testing & Inspection
Electrical Testing: Flying Probe Test, Bed-of-Nails Test
Visual Inspection: 3D SPI Solder Paste Inspection, AOI
Reliability Testing: Thermal Cycling, Vibration Test, Drop Test
Application Fields
? Smart Home
Smart speakers, smart lighting controllers
Home security devices, environmental monitors
Smart appliance control boards
? Personal Electronics
Wearable devices, smartwatches
Power banks, wireless chargers
Bluetooth earphones, portable audio devices
? Entertainment & Communication
Gaming accessories, VR/AR devices
Network communication modules, routers
Consumer drone control boards
Service Workflow
Design Review - Free DFM/DFA analysis for manufacturability optimization
Component Procurement - BOM analysis, sourcing, and supply chain management
PCB Fabrication - Multi-layer board manufacturing and quality inspection
SMT Assembly - Fully automated high-speed placement and reflow soldering
DIP Assembly - Through-hole component insertion and wave soldering
Testing & Validation - Comprehensive functional and reliability testing
Assembly & Packaging - Final assembly and anti-static packaging
Logistics & Delivery - Global shipping and after-sales support
Quality Control System
Certifications & Standards
ISO 9001:2015 Quality Management System
ISO 14001 Environmental Management System
UL Certified Manufacturing Capability
RoHS, REACH Environmental Compliance
Quality Commitment
First-Pass Yield > 98.5%
Defect Rate < 500 ppm
12-Month Quality Warranty
Full-Process Traceability System
Why Choose Our PCBA Service?
Proven Industry Experience - Over 10 years in consumer electronics PCBA manufacturing
One-Stop Solution - End-to-end service from design to final assembly
Cost Efficiency - Process optimization to reduce overall project cost
Rapid Response & Support - 24/7 technical support from a dedicated team
Stable Supply Chain - Long-term partnerships with leading component suppliers
Request a Custom Quote
Please provide the following for a tailored quotation:
Gerber files and BOM list
Product application and quantity requirements
Special process requests
Desired delivery timeline
Contact Us: Our engineering team is ready to provide professional consultation and customized PCBA solutions to help bring your consumer electronics to market faster!
